DX-2987-4 16P SMT Audio Connector
Pin Max OD：2mm
Total Length：7.5mm
Rating：12V/1.0A
Spring Force：70g±20%
Contact Resistance：100mΩ
Cycle Life：10,000 cycles
Material：C3604 brass, 5U gold plating
P3097
- 16Pin combined patch layout, realizes simultaneous power & audio signal transmission for multi-section audio links
- SMT tape & reel packing compatible with automatic mounter for high-volume mass production
- Rigid C3604 brass pin maintains consistent spring force after frequent mating
- 5U gold plating shields against oxidation & signal interference for pure audio output
- Full custom mold service to match customer’s audio equipment structural & electrical requirements
Multi-section internal connection for speakers, portable sound boxes, audio players and multimedia sound modules. Custom pin count, dimension and spring force available.
